TOMOYO 20-30KW low-noise diesel generator sets, box-type diesel generator series, high-strength power body, reduced power cylinder wear, low loss, high efficiency, low temperature rise, high reliability, and sufficient power.

Type: DZ-TO-20/30KW

Rated power: 20/25/30KW

Backup power: 22/27/33KW

Rated frequency: 50/60HZ

Rated voltage: 220/380V

Structure type: Silent type

Altitude used: <1500M

Power factor: 0,8/1.0

Regulation method: AVR (Automatic Voltage Regulator)

Number of phases: Three-phase

Frequency adjustment: (%): ≤ ±0.5 (steady state)

Voltage fluctuation: (%): ≤ ±0.5

Fuel type: 0# - 10# diesel

Starting method: Electric start (fully automatic optional)

Working hours: 8-12 hours

Lubricating oil tank: 13L

No-load fuel consumption: 226g/kw.h

Fuel tank capacity (L): 50/60/50L

Noise level (dB/7m): 68-76

Wiring method: Three-phase four-wire, Y-connection

Protection rating: IP22

Insulation class: Class H

Rated speed: 3000 rpm

Dimensions (L*W*H) (mm): 1500*710*1000MM /1500*710*1000MM/1500*710*1000MM

Net weight (KG): 550/550/580KG
