TOMOYO 300A-600A Diesel Generator-Welder (Manual Welding / Gas-Shielded Welding)，Suitable for various construction scenarios such as field operations, steel structure work, pipeline welding, and municipal emergency repairs; offers a choice of engines (including Kubota and Yanmar) and multiple welding methods.

Model: TO300A-J/350A-J/TO400A-J/TO500A-J/TO600A-J

Welder Specifications:

Rated Current: 300A/350A/400A/500A/630A

Welding Type: Manual Welding / Gas-Shielded Welding

Current Adjustment: 60–300A/60-350A/60-400A/60-500A/60-630A

Voltage Adjustment Range: 17–50V

No-Load Output Voltage: 70V

Efficiency: 85%

Electrode Diameter: 0–6.0mm/0–6.0mm/0-8.0mm/0-8.0mm/0-8.0mm

Welding Wire Diameter: 1.2mm/1.2mm/1.0-1.6mm/1.0-1.6mm/1.0-1.6mm

Gas-Shielded Welder: Semi-automatic

Welding Grade: Industrial

CO2 Gas Flow Rate: 15–20L/min

Generator Specifications:

Rated Power: 20kW/20KW/30KW/30KW/50KW

Standby Power: 21kW/21KW/31KW/31KW/52KW

Rated Voltage: 230V/400V

Rated Frequency: 50Hz

Insulation Class: Class H

Power Factor: 0.8/0.9/1.0

Motor Type: Brushless, 4-pole

Voltage Customization: Supported

Engine Specifications:

Engine Model: TOTO498T/TOTO698T

Engine Power: 25kW / 1500 rpm//25kW / 1500 rpm//33kW/1500rpm//33kW/1500rpm//62kW/1500rpm

Air Intake: Naturally Aspirated/Naturally Aspirated/Turbocharged/Turbocharged/Turbocharged and intercooled

Cooling Method: Forced Water Cooling

Number of Cylinders: 4

No-Load Fuel Consumption: 209g/kW·h

Fuel Type: Diesel

Displacement: 3.65L

Starter Motor: 12V/24V

Unit Specifications:

Preheating Device: Optional

Remote Welding Adjustment: Customization required

Starting Method: Electric Start

Battery Charging Module: Included

Weight (Approx.): 750kg/750kg/750kg//750kg/950KG

Structure Type: Enclosed (Canopy)

Dimensions (Approx.): 1550 x 800 x 1200MM/1550 x 800 x 1200MM/1550*800*1200mm/1550*800*1200mm/1800*900*1300mm
